Vicell V-series PVC TDS

Core Material Expert -- always beyond excellence

vicell -V Product performance

Vicell V,a closed cell cross-linked PVC structural foam with excellent specific strength,Especially high temperature molding process system ,is applicable for a wide range of composite materials.Vicell V foam has excellent chemical stability and extremely low water absorption, and is able to work together with a variety of resin systems, including epoxy, polyester and vinyl ester resins. Vicell V foam provides various sizes and specifications, and can be processed by various forms of machining according to customer requirements.In addition to having the same excellent basic physical characteristics,the different series of product provide different characteristics.
◆Excellent comprehensive mechanical properties
◆Excellent compatibility with resin and good chemical stability
◆Low water absorption and good weather resistance
◆High temperature resistance
◆Flame resistance, sound and heat insulation and shock absorption
◆Good process-ability
◆Be applicable for various dry or wet molding processes concerning composite materials, such as RTM, mould pressing, etc.
◆It is used in the wind turbine blade and engine room cover, ship, rail transit, sports equipment, building materials and other fields

Vicell V-series products in standard sizes

标准板材

Standard plate

测试标准

单位Unit

V45

V60

V80

V100

V130

V160

V200

V250

Test standard

宽度 Width

mm

1200

1130

1020

980

850

800

750

700

长度 Length

mm

2600

2440

2180

2020

1900

1800

1600

1500

厚度 Thickness

mm

5-95

5-95

5-80

5-66

5-55

5-55

5-50

5-50



Performance indicators

(Comparison of measured mechanical properties)

性能Property

测试标准 Test standard

指标Unit

值Value

V45

V60

V80

V100

V130

V160

V200

V250

密度Density

ISO 845

Kg/m3

平均值 Mean

45

60

80

100

130

160

200

250

区间 Range

40-53

54-69

72-92

90-115

120-150

151-180

180-225

230-275

压缩强度Z

Compression strength

ISO 844

MPa

平均值 Mean

0.65

0.95

1.45

2.1

3.2

3.9

5.5

7

最小值 Minimum

0.5

0.8

1.2

1.7

2.6

3.3

4.5

6

压缩模量Z

Compression modulus

ISO 844

MPa

平均值 Mean

50

80

110

140

180

230

300

380

最小值 Minimum

35

65

85

110

145

190

250

330

拉伸强度X1

Tensile strength

ASTM D638

MPa

平均值 Mean

0.98

1.35

2

2.7

4

4.5

6

7.5

最小值 Minimum

0.85

1.05

1.6

2.2

3

3.7

4.8

5.5

拉伸模量X1

Tensile modulus

ASTM D638

MPa

平均值 Mean

38

50

70

85

120

135

175

230

最小值 Minimum

30

38

50

65

95

115

140

160

平拉强度Z2

Tensile strength

ASTM C297

MPa

平均值 Mean

1.5

1.8

2.5

3.5

4.8

5.3

7.3

8.8

最小值 Minimum

1

1.5

2

2.6

3.5

3.8

6.5

7.8

平拉模量Z2

Tensile modulus

ASTM C297

MPa

平均值 Mean

55

75

110

135

180

200

270

300

最小值 Minimum

40

60

85

110

130

180

230

250

剪切强度XZ

Shear strength

ISO 1922

MPa

平均值 Mean

0.55

0.82

1.25

1.75

2.5

2.80

3.5

4.7

最小值 Minimum

0.5

0.73

1.05

1.4

2.1

2.2

3.2

4.2

剪切模量XZ

Shear modulus

ISO 1922

MPa

平均值 Mean

16

22

30

42

55

64

75

100

最小值 Minimum

14

19

25

35

45

55

68

84

断裂延伸率XZ

Shear breaking elongation

ISO 1922

%

平均值 Mean

15

23

30

35

40

42

45

45

最小值 Minimum

8

10

15

15

20

22

25

25



Application areas

Vicell V,a closed cell cross-linked PVC structural foam with excellent specific strength,Especially high temperature molding process system ,is applicable for a wide range of composite materials.Vicell V foam has excellent chemical stability and extremely low water absorption, and is able to work together with a variety of resin systems, including epoxy, polyester and vinyl ester resins. Vicell V foam provides various sizes and specifications, and can be processed by various forms of machining a
